AMPROBE AMB-45 STOCK DISPONIBLE
​


MEGOHMETRO – > MARCA: AMPROBE -> MODELO: AMB-45 ; REALIZAMOS ENVIOS A TODO EL PERU AMPROBE ENTREGA INMEDIATA

R Tests insulation of wires, cables, transformers and electrical motors
R Comes as a complete kit including test leads and PC software
R Selectable test voltages up to 1000V
R Programmable timer to perform the Dielectric Absorption Ratio Test
R Sensitive Ohmmeter for checking resistance of motor windings
R Built in voltmeter
R Fast and easy to use, rugged durable design
R Internal memory to store measurements for future reference
R Data download to PC
R Safety CAT III 600V

GENERAL SPECIFICATION:
• Display:
70 x 46mm LCD with 60 segment analog bar Indicator.
• Over range Indication:
«OL» will be shown on the LCD Panel when an out of range measurement is made.
• Low Battery Indication:
The symbol is displayed indicating a low battery condition.
• Sampling Rate:
2.5 times/sec Digital Display; 10 times/sec Bar Graph
• Power Source:
1.5V AA size Battery X 8
• Operating Temperature and Humidity:
0
0C to 400C ( 320
F to 1040
F ), below 80% RH
• Storage Temperature:
-100C to 600C ( 140
Fto 1400
F )
• Dimension:
230 x 116 x 62 mm ; 9 x 4.6 x 2.4 inch
• Weight:
Approx. 750g(with battery)
• Accessories:
Test Lead, Large Jaw Alligator Clips, Batteries, Instruction Manual, Carrying Case, software, RS-232 cable.

VIDEO REFERENCIAL:

​
