AMPROBE AMP-330 STOCK DISPONIBLE
​


PINZA AMPERIMETRICA – > MARCA: AMPROBE -> MODELO: AMP-330 ; REALIZAMOS ENVIOS A TODO EL PERU AMPROBE ENTREGA INMEDIATA

Pinza amperimetrica, 1000A AC/DC, 1000V AC/DC, 60K?, TRU RMS – s
Features
• True-RMS
• Motor Testing Capabilities
– Motor rotation
– 3-phase sequence testing
– Inrush current monitoring
during motor start-up
• HVAC Features
– Temperature measurement;
User selectable °F or °C
– DC Microamps for flame
sensor testing
– Capacitance measurement
for start and run motor
capacitors
• Amp-Tip Function
• Low Pass Filter for variable
frequency drives
• Safety Rated:
CAT III 600 V (AMP-310, AMP-320)
CAT IV 600 V, CAT III 1000 V (AMP-330)
AMP-310
AC Clamp Meter
HVAC
AMP-320
AC/DC Clamp Meter
Electrical Motor
Maintenance
AMP-330
AC/DC 1000 A Clamp Meter
Industrial Motor
Maintenance
A

AMP-300 Series Product Details Model AMP-310 AMP-320 AMP-330 Safety Rating CAT III 600 V CAT III 600 V CAT IV 600 V CAT III 1000 V Voltage Up to 600 V AC/DC Up to 600 V AC/DC Up to 1000 V AC/DC AC Current Up to 600 A Up to 600 A Up to 1000 A DC Current – Up to 600 A Up to 1000 A Frequency 5 to 999 Hz Resistance 0 to 60 kΩ Capacitance 0.0 to 2500 µF Temperature • • •
